I. Applicable Materials: Suitable for small-sized, flat, strip, round and irregular-shaped materials for weighing in small specifications, such as:

★ Small particle shapes: Chinese herbal decoction pieces, tea, seeds, corn kernels, pills, beans, etc.

II. Functional Features:

◆ Factory parameter recovery function;

◆ Supports 20g and 200g weight calibration;

◆ When there is a shortage of materials, it can automatically pause to make the weighing accuracy more stable;

◆ The display has a built-in help menu, facilitating learning and use;

◆ 100 sets of parameter settings capacity, enabling the storage of various material settings;

◆ 15 types of standard language selection configuration;

◆ During operation, the amplitude of each line vibration motor can be automatically adjusted, making the material addition more uniform and improving the combination accuracy;

◆ Adopting high-precision HBM sensor configuration and high-performance stepper motor side drive method, different from traditional stepper motors, it can better control the vibration of the sensor when opening the material door, significantly reducing the peak value of the sensor's reading when subjected to vibration;

◆ Free port configuration, which can be flexibly set to be more conducive to the cooperation with packaging machines.

III. Mechanical Characteristics and Product Features:

● New type of double parallel line vibration motor, with more stable amplitude;

● Weighing-type material detection, capable of precisely controlling the addition time of the feeding mechanism;

● Special V-shaped line vibration tray, specifically designed for small-weight materials, conducive to improving combination accuracy and combination probability;

● Side-driven aluminum box, reducing the distance from the material to the sensor center, improving the accuracy of sensor reading;

● Integrated chassis and middle base enhance the rigidity and strength of the machine, making the stability time of the hopper shorter.

IV. Technical Specifications:
