◆ Factory parameter restoration function;
◆ Can automatically pause when there is a shortage of materials, making the weighing accuracy more stable;
◆ High-performance weighing sensor with stronger anti-interference ability, achieving stable weighing;
◆ The display comes with a help menu, facilitating learning and use;
◆ 15 standard language selection configurations;
◆ Free port configuration, allowing for flexible settings that are more conducive to the cooperation with packaging machines.
● The maximum length of the material can reach 250MM;
● The discharge chute has a 60-degree small angle, making the material fall more smoothly;
● The unique small pointed cap main vibration plate can avoid the material staying at the main vibration center;
● The positive and reverse adjustable rotating main vibration machine is configured with a power transmission disc;
● The sawtooth rotating rods between the linear vibration plates are designed, driven by the power transmission disc, which can better feed the long and difficult-to-separate material into the storage hopper.
| Model number | PGMT/SP-10H | PGMT/SP-14H |
| Weighing range | 200~500g | 100~800g |
| Accuracy | 0.5~3g | 0.5~3g |
| Fastest speed | 20PPM | 35PPM |
| Hopper capacity | 2.5L | |
| Control Panel | 7.0" touch screen | |
| Supplementary Components | Gravel hopper / oversize separation device | |
| Drive System | Stepper motor | |
| Power Specifications | 220V / 1000W / 50/60Hz / 10A | 220V / 2000W / 50/60Hz / 12A |
| Package Dimensions (mm) | 1680(L)x1100(W)x1500(H) | 1700(L)x1200(W)x1500(H) |
| Weight | 420KG | 500KG |
1.Application Special designed for weighing small, regular-shape products such as sugar, salt, seeds, rice, sesame, glutamate, and milk powder, coffee powder and seasoning powder, etc. 2. Main Features ◆ High-precision digital load cell. ◆ Controlled through an industrial control panel with an extremely powerful processor. ◆ Multilanguage choice (Translation is needed for some specific language). ◆ Different authority management. ◆ Weighing different products at one discharge. ◆ Parameters can be freely adjusted during running condition. ◆ New generation design, each actuator board can be exchanged with each other. ◆ Weigh hopper opening/closing controlled by step motors.
Applicable Materials: Suitable for quantitative weighing of soft and sticky materials, such as cheese and QQ sugar.
Applicable Materials: Suitable for bagged or granular material weighing, such as: ★ Small bagged: Coptis chinensis, coffee, black sesame paste, soy milk powder, biscuits, cereal; ★ Large granules: Jellies, candies, faucet heads.
Applicable Materials: Suitable for quantitative weighing of soft and sticky materials, such as cheese and QQ sugar.
Applicable Materials: Suitable for quantitative weighing of long strip materials when they fall vertically for packaging, such as: ★ Long strip materials: chopsticks, sausages, finger cakes, biscuit strips, steel nails, etc. in the form of strips.
Applicable Materials: Suitable for quantitative weighing of large-sized or large-capacity materials such as salads, fruits, and vegetables, etc. For example: ★ Large-sized materials: potatoes, onions, tomatoes, carrots, etc.; ★ Large-capacity materials: vegetable salads, spinach, broccoli, etc.
Applicable Materials: Suitable for quantitative weighing of frozen food products, such as: ★ Frozen foods: dumplings, tangyuan, meatballs, squid rings, shrimp, fish pieces, etc.
Applicable Materials: Suitable for quantitative weighing of various micro-particle materials, such as: ★ Micro-particles: Rice, chicken essence, monosodium glutamate, sugar, corn flour, tea powder, etc. for quantitative weighing.
Based on local services for leading food supply chains such as Shuanghui and Weilong, it also radiates to thousands of small and medium-sized food processing factories across the country. The export business has been steadily expanded, with equipment sold to overseas markets such as Southeast Asia, Central Asia, the Middle East, and South America, meeting the automation upgrade needs of cross-border food production enterprises.
