Applicable Materials: Suitable for quantitative weighing of long strip materials when they fall vertically for packaging, such as: ★ Long strip materials: chopsticks, sausages, finger cakes, biscuit strips, steel nails, etc. in the form of strips.
★ Long strip materials: chopsticks, sausages, finger cakes, biscuit strips, steel nails, etc. in the form of strips.
◆ Factory parameter recovery function;
◆ Can automatically pause when there is a shortage of material, making the weighing accuracy more stable;
◆ High-performance weighing sensor with stronger anti-interference ability, achieving stable weighing;
◆ The display has a built-in help menu, facilitating learning and use;
◆ 15 standard language selection configurations;
◆ Multi-level anti-interference ability selection, suitable for different weighing requirements in different places;
◆ Free port configuration, allowing for flexible settings that are more conducive to the cooperation with packaging machines.
● The maximum length of the material can reach 150MM;
● The main vibration plate has a channel design, allowing the material to flow better towards the linear vibration plate;
● The linear vibration plate has a multi-step design, which can effectively control the density of different sections of the material and has a unique effect on the weighing of small-sized long strip materials;
● Independent discharge chute, enabling the material to be discharged vertically and neatly into the packaging machine;
● A cylinder or limiting device is added in the hopper to keep the material vertically downward, effectively avoiding the material falling horizontally.
| Model number | PGMT/MC-14H | PGMT/SP-14H |
| Weighing range | 5~50g | 10~250g |
| Accuracy | 0.1~1.0g | 0.1~1.0g |
| Fastest speed | 70PPM | 70PPM |
| Hopper capacity | 0.5L/2.5L | |
| Control Panel | 7.0" touch screen | |
| Supplementary Components | Gravel hopper / oversize separation device | |
| Drive System | Stepper motor | |
| Power Specifications | AC220V / 1100W / 50/60Hz / 8A | AC220V / 2000W / 50/60Hz / 12A |
| Package Dimensions (mm) | 920(L)x1150(W)x920(H) | 1700(L)x1200(W)x1500(H) |
| Weight | 250KG | 500KG |
1.Application Special designed for weighing small, regular-shape products such as sugar, salt, seeds, rice, sesame, glutamate, and milk powder, coffee powder and seasoning powder, etc. 2. Main Features ◆ High-precision digital load cell. ◆ Controlled through an industrial control panel with an extremely powerful processor. ◆ Multilanguage choice (Translation is needed for some specific language). ◆ Different authority management. ◆ Weighing different products at one discharge. ◆ Parameters can be freely adjusted during running condition. ◆ New generation design, each actuator board can be exchanged with each other. ◆ Weigh hopper opening/closing controlled by step motors.
Applicable Materials: Suitable for quantitative weighing of soft and sticky materials, such as cheese and QQ sugar.
Applicable Materials: Suitable for bagged or granular material weighing, such as: ★ Small bagged: Coptis chinensis, coffee, black sesame paste, soy milk powder, biscuits, cereal; ★ Large granules: Jellies, candies, faucet heads.
Applicable Materials: Suitable for quantitative weighing of soft and sticky materials, such as cheese and QQ sugar.
Applicable Materials: Suitable for quantitative weighing of large-sized or large-capacity materials such as salads, fruits, and vegetables, etc. For example: ★ Large-sized materials: potatoes, onions, tomatoes, carrots, etc.; ★ Large-capacity materials: vegetable salads, spinach, broccoli, etc.
Applicable Materials: Suitable for quantitative weighing of frozen food products, such as: ★ Frozen foods: dumplings, tangyuan, meatballs, squid rings, shrimp, fish pieces, etc.
Applicable Materials: Suitable for quantitative weighing of various micro-particle materials, such as: ★ Micro-particles: Rice, chicken essence, monosodium glutamate, sugar, corn flour, tea powder, etc. for quantitative weighing.
Based on local services for leading food supply chains such as Shuanghui and Weilong, it also radiates to thousands of small and medium-sized food processing factories across the country. The export business has been steadily expanded, with equipment sold to overseas markets such as Southeast Asia, Central Asia, the Middle East, and South America, meeting the automation upgrade needs of cross-border food production enterprises.
