Equipped with an 18.5-inch full-color touch screen, supporting Chinese, English and multiple optional languages.
Built-in industrial air conditioner to stabilize internal temperature and humidity from external environmental interference.
Adopts variable frequency drive motors; running speed is adjustable as required.
Supports manual or automatic zero reset, as well as dynamic zero tracking function.
Maximum empty machine detection precision: 0.6mm metal sphere, 0.4×2 stainless steel wire, 1.2mm ceramic ball, 1.2mm glass ball.
Multiple safety interlock protections for stable and reliable operation; radiation level ＜0.4μSv/h
The intelligent X-ray defect inspection system is widely used for foreign body detection in packaged seeds, confectionery, frozen food, snack food, dairy products, baked goods, fruit & vegetable products and aquatic products. It can effectively identify hard contaminants such as metal, glass, ceramics, stones and bones inside food and pharmaceuticals.
Technical Parameters
Channel width 400mm
| Pass the height | 160mm |
| Overall Dimensions (Length × Width × Height) | 1220mm×900mm×1710mm |
| Detection Mode | Boxed / Bulk Mode |
| Elimination method | Push rod rejection |
| traffic light | X-ray lamp, power indicator light, system error indicator light |
| Conveyor belt height | 710mm+80mm |
| Maximum load capacity | 10kg |
| Belt speed | Speed is adjustable from 5 to 60 meters per minute |
| Voltage/Power | Single-phase 220V/50Hz, 2KW |
Based on local services for leading food supply chains such as Shuanghui and Weilong, it also radiates to thousands of small and medium-sized food processing factories across the country. The export business has been steadily expanded, with equipment sold to overseas markets such as Southeast Asia, Central Asia, the Middle East, and South America, meeting the automation upgrade needs of cross-border food production enterprises.
