Scope of application: Block materials: dried tofu, fish snacks, eggs, candies, red dates, oatmeal, chocolate, biscuits, peanuts, green soybeans, rock sugar, pistachios, daily necessities, puffed food, etc. Granular materials: crystalline monosodium glutamate, granular medicines, capsules, seeds, chemical raw materials, granulated sugar, chicken essence, melon seeds, nuts, pesticides, fertilizers, feeds
The body is waterproof and easy to clean;Mechanical transmission;The pneumatic components adopt the Festol brand importedfrom Germany,with stable quality and long service life.
Technical Parameters：
| Model | MW8-200DZC Electronic Scale Automatic Bag-given Packaging Machine |
| Packaging materials | Self standing bags,handbags,zippered bags,four sided sealing bags,three sided sealing bags,paper bags and other composite bags |
| Bag size | Width (W): 80-230mm Length (L): 150-380mm |
| Fil range | 10-2500g (Depending on product type) |
| Packaging speed | 40-60 packages per minute |
| External dimensions | 2200x1500×2200mm(LxWxH) |
| Machine weight | 1550KG |
| Compressed air consumption | ≥0.6 cubic meters per minute (Compressed air shall be supplied by the user) |
Main optional configurations：
Material metering filling machine, working platform, weight sorting scale, material elevator, finished product conveying elevator, metal detector
Functions and Features：
-The packaging system consists of a bag packaging machine,a work platform,an electronic scale, and a Z-shaped elevator.
-Fast packaging speed and stable performance.-Having a waterproof system makes cleaning more convenient;Using a color touch screen for easy operation.
-Innovatively solve various packaging problems at reasonable costs.
-Low packaging material loss. This machine uses prefabricated bags with perfect patterns and excellent sealing quality, which improves product grade.
Main standard components：
| 1.Bag loading system | 5.Heat sealing system |
| 2.Zipper opening system | 6.PLC control system |
| 3.Bag opening device | 7.Output system |
| 4.Material unloading system |
Workflow:
Take the bag Print the date Open the bag Fill 1 Fill 2 Heat sealing 1 Heat sealing 2 Shaped finished output
Bean products,meat products,egg products,pickled vegetables and other leisure foods.
Scope of application： Products with heavy weight and slight stickiness such as chow mein, self-heating rice, large chunks of meat products, as well as materials that cannot be automatically metered
